Cavity: T-5A
Capacity: 12 gpm (.25 inch)
Maximum Operating Pressure: 5000 psi
Maximum Valve Leakage at 110 SUS (24 cSt): 10 drops/min.
Adjustment – No. of CCW Turns from Fully Closed to Fully Open: 5

Needle valves with reverse-flow check are fully adjustable orifices used to regulate flow. They are infinitely adjustable from fully closed up to the maximum orifice diameter. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1. They are not pressure compensated.
