Capacity: 30 gpm
Cavity: T-2A
Pilot Ratio: 3:1
Maximum Recommended Load Pressure at Maximum Setting: 3075 psi
Maximum Setting: 4000 psi

Counterbalance valves with pilot assist are meant to control an overrunning load. The check valve allows free flow from the directional valve (port 2) to the load (port 1) while a direct-acting, pilot-assisted relief valve controls flow from port 1 to port 2. Pilot assist at port 3 lowers the effective setting of the relief valve at a rate determined by the pilot ratio.
